透过车架、前叉、轮组以及零配件的绝佳组合，工程师以追求整车优化的竞赛设计，打造出TCR ADV PRO 2 DISC，轻松驾驭你的爬坡速度和弯道冲刺能力；
作为全能型公路竞赛用车，超强刚性征服您的更高的登峰挑战，轻量化的同时拥有公路竞赛所需的全方位性能。
| FRAME/车架 | |
|---|---|
| 车架 | Advanced-Grade Composite |
| 前叉 | Advanced-Grade Composite, Full-Composite OverDrive 2 Steerer |
| Components/组件 | |
|---|---|
| 车把 | New Giant Contact SL |
| 车首竖杆 | New Giant Contact SL |
| 座垫杆 | New Giant Variant, Composite |
| 座垫 | Giant Fleet SL |
| Drivetrain/传动系统 | |
|---|---|
| 变速把手 | Shimano 105 Hydraulic |
| 前变速器 | Shimano 105 |
| 后变速器 | Shimano 105 |
| 刹车 | Shimano 105 Hydraulic |
| 飞轮 | Shimano 105, 11x30 |
| 链条 | KMC X11SL-1 |
| 大齿盘 | Shimano 105, 36/52 |
| 中轴 | Shimano, PressFit RS500 |
| Wheels/轮组 | |
|---|---|
| 轮圈 | New Giant SLR 1 42 Carbon Disc Wheel System with GIANT patented DBL (Dynamic Balanced Lacing) technology |
| 轮胎 | Giant Gavia COURSE 1 Tubeless, 700x28mm (25c), 60 TPI , Folding |
| Other/其它 | |
|---|---|
| 其他 | RideSense Bluetooth Computer Mount with Giant, Garmin, Wahoo tray |
XS | S | M | ML | L | XL | ||
A | SEAT TUBE LENGTH (inch) | 26.8 | 28 | 29.1 | 30.3 | 31.1 | 32.3 |
B | SEAT TUBE ANGLE | 74.5° | 73.5° | 73.0° | 73.0° | 73.0° | 72.0° |
C | TOP TUBE LENGTH (inch) | 20.3 | 21.1 | 21.7 | 22.4 | 22.8 | 23.8 |
D | HEAD TUBE LENGTH (inch) | 4.8 | 5.2 | 5.8 | 6.6 | 7.4 | 8 |
E | HEAD TUBE ANGLE | 71.0° | 72.5° | 73.0° | 73.0° | 73.0° | 73.0° |
F | FORK RAKE (inch) | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 | 1.8 |
G | TRAIL (inch) | 2.7 | 2.4 | 2.2 | 2.2 | 2.2 | 2.2 |
H | WHEELBASE (inch) | 38.3 | 38.2 | 38.4 | 39.3 | 39.6 | 40.2 |
I | CHAIN STAY LENGTH (inch) | 15.9 | 15.9 | 15.9 | 15.9 | 15.9 | 15.9 |
J | BOTTOM BRACKET DROP (inch) | 2.8 | 2.7 | 2.7 | 2.6 | 2.6 | 2.6 |
K | STACK (inch) | 20.4 | 20.8 | 21.5 | 22.1 | 22.9 | 23.4 |
L | REACH (inch) | 14.6 | 14.9 | 15.1 | 15.7 | 15.8 | 16.2 |
M | STAND OVER HEIGHT (inch) | 28.5 | 29.2 | 30.1 | 31 | 31.7 | 32.4 |
N | HANDLEBAR WIDTH (inch) | 15.7 | 15.7 | 16.5 | 16.5 | 17.3 | 17.3 |
O | STEM LENGTH (inch) | 3.1 | 3.5 | 3.9 | 4.3 | 4.3 | 4.7 |
P | CRANK LENGTH (inch) | 6.7 | 6.7 | 6.8 | 6.8 | 6.9 | 6.9 |
Q | WHEEL SIZE | 700C | 700C | 700C | 700C | 700C | 700C |
